6-122

Model HM74 Series

DC

Nominal

DC Current

Resistance

Resistance

Part

µH

Amps

m

Ω

m

Ω

Number

±20%

Max.

Typ.

HM74-R47

0.47

26.0

1.1

0.9

HM74-R85

0.85

19.0

2.1

1.8

HM74-1R4

1.40

14.5

3.6

3.0

HM74-2R1

2.10

12.5

4.4

3.7

HM74-3R0

3.00

8.0

11.9

9.9

HM74-4R0

4.00

7.5

13.7

11.4

HM74-5R1

5.10

7.0

15.5

12.9

HM74-6R3

6.30

6.5

17.2

14.3

SPECIFICATIONS

Notes: (1) Inductance measured at 100kHz, 0.25V without DC current.

(2) Rated DC current is the approximate current at which inductance will be decreased by 20% from

its initial (zero DC) value or the DC current at which

∆T = 50°C, whichever is lower.

(3) DC resistance measured at 20°C.

HM74

1RO

TR

Model Series

Packaging Option:

TB = Tubes (32 Units /Tube)

TR = Tape & 13" Reel (250 Units /Reel)

Inductance Code:

First two digits are significant.

Last digit denotes number of

trailing zeros. Values below

10

µH "R" denotes decimal point.

ORDERING INFORMATION
