SE2525L

RangeCharger™ 2.4GHz Power Amplifier with Power Detector

Preliminary Information

28-DST-01 Rev 2.1 Apr-25-2006

Confidential

3 of 12

QA042506

Absolute Maximum Ratings

These are stress ratings only. Exposure to stresses beyond these maximum ratings for a long period of time may

cause permanent damage to, or affect the reliability of the device. Avoid operating the device outside the

recommended operating conditions defined below. This device is ESD sensitive. Handling and assembly of this

device should be at ESD protected workstations.

Symbol

Definition

Min.

Max.

Unit

-0.3

4.0

V

Bias Control Voltage

-0.3

4.0

V

Power Amplifier Enable

-0.3

4.0

V

IN

RF Input Power

-

4.0

dBm

Storage Temperature Range

-40

+150

°C

Maximum Junction Temperature

-

+150

°C

Recommended Operating Conditions

Symbol

Parameter

Min.

Max.

Unit

2.7

3.6

V

Ambient Temperature

-40

85

°C

DC Electrical Characteristics

EV1 evaluation board, unless otherwise noted.

Symbol

Parameter

Conditions

Min.

Typ.

Max.

Unit

Supply Current

signal, BT = 0.45

-

230

-

mA

Supply Current

signal, 64 QAM

-

160

-

mA

Supply Current

-

340

-

mA

Supply Current

-

10

-

µA

Regulator Voltage

(1)

-

2.5

2.75

V

Regulator current

-

-

-

500

µA

Logic High Voltage

1.3

-

V

Logic Low Voltage

0

-

0.5

V

Bias voltage

-

0

-

V

Bias current

-

-

120

µA
