MA4ST2000 Series

2

Ultra High Ratio Si Hyperabrupt Varactor Diode

Part Number

Ct*

(pF)

Capacitance Ratio

Rs**

(Ohm)

Typ.

Min.

Nom.

Max.

Typ.

Typ.

Typ.

Typ.

Typ.

Max.

MA4ST2200

7.68

3.66

4.07

4.48

0.70

0.47

16.3

11.0

3.84

4.6

MA4ST2300

34.2

16.2

18.0

19.8

2.67

1.85

18.5

12.8

0.95

1.2

MA4ST2400

60.3

28.6

31.8

34.9

4.98

3.27

18.4

12.1

0.67

0.9

MA4ST2500

86.4

41.4

46.0

50.6

6.68

4.64

18.6

12.9

0.61

0.8

MA4ST2600

113.3

54.3

60.3

66.4

9.14

6.27

18.1

12.4

0.54

0.7

Equivalent

RoHs

Compliant

Part

Number

MAVR-002200-XXXXXX

1

MAVR-002300-XXXXX

1

MAVR-002400-XXXXXX

1

MAVR-002500-XXXXXX

1

MAVR-002600-XXXXXX

1

Typical Series Resistance vs. Biasing Voltage

Typical Capacitance vs. Biasing Voltage

Typical Capacitance Change vs. Temperature

Typical Series Resistance vs. Frequency

0

20

40

60

80

100

120

140

01

23

45

Biasing Voltage (V)

MA4ST2200

MA4ST2300

MA4ST2400

MA4ST2500

MA4ST2600

0.0

1.0

2.0

3.0

4.0

5.0

6.0

7.0

0

1

23

45

Biasing Voltage (V)

MA4ST2200

MA4ST2600

MA4ST2400

MA4ST2300

MA4ST2500

0.0

1.0

2.0

3.0

4.0

5.0

6.0

7.0

8.0

200

300

400

500

Frequency (MHz)

MA4ST2500

MA4ST2200

MA4ST2300

MA4ST2400

MA4ST2600

-0.08

-0.04

0

0.04

0.08

-40

-15

10

35

60

85

Temperature (degree C)
