MSVB Series

Motor-driven Slide Potentiometer, 1M cycles

01

Features

100mm long travel

Programmable and precise slide pattern

Touch sensitive track

Custom options available

Applications

Panel control that requires analog signal change via sliding. Popular

for high-end audio mixer, stage lighting, or video editing

Potentiometer Specification

How to order

MSVB

Series

Travel

Lever

Resistance

502

5K ohm

103 10K ohm

203 20K ohm

503 50K ohm

104 100K ohm

254 250K ohm

504 500K ohm

100 100mm

Output

S Single

D Dual

M3 8.2mm

Operating Temperature

-10°C to +70°C

Operating Force

10 - 60 gf max.

Total Resistance

5, 10, 20, 50, 100, 250, 500 K

Total Resistance Tolerance

±20%

Resistance Taper

Standard linear , custom linear or audio

Insulation Resistance

100 M min. at 250 VDC

Operating Voltage

5VDC

Max. Operating Current

800mA

Slide Travel

100mm

Life Cycle

1,000,000
