Product Search Data Sheet

SFSCE10M7WF05-R0

Note: This datasheet may be out of date.

Please download the latest datasheet of SFSCE10M7WF05-R0 from the official website of Murata

Manufacturing Co., Ltd.

http://www.murata.com/en/products/productdetail?partno=SFSCE10M7WF05-R0

Attention

1.This datasheet is downloaded from the website of Murata Manufacturing Co., Ltd. Therefore, it’s specifications are subject to change or our products in it may be discontinued

without advance notice. Please check with our sales representatives or product engineers before ordering.

2.This datasheet has only typical specifications because there is no space for detailed specifications.

Therefore, please review our product specifications or consult the approval sheet for product specifications before ordering.

URL : https://www.murata.com/

Last updated04/15/2024

Applications

Unsuitable

Applications

Please be sure to read and comply with

these "Precautions for use."

Specific

Applications

Consumer equipment

Please refer to Our Website and

specifications, etc. for information about

the performance, functions, quality,

management, and safety required for

the above applications, and use

Products after confirming the

performance and reliability of the actual

Product.

Appearance & Shape

Packaging Information

Packaging

Specifications

Standard

Packing

Quantity

-R0

180mm Embossed Tape

1500

Features

SFSCE series are chip surface mount filters available for 3dB

bandwidth at 700kHz to 1.3MHz (more than twice width compared

with current types). They have 1.0mm max. thickness and small

mounting area (4.5x3.8mm).

Features

1. The filters are mountable by automatic placers.

2. They are slim, at only 1.0mm max. thickness, and have a small

mounting area (4.5x3.8mm) enabling flexible PCB design.

3. Available lead (Pb) free solder reflow.

4. Operating temperature range: -20 to +80 (degrees C), Storage

temperature range: -40 to +85 (degrees C)

1 of 3
