NEMA Motor Starter, Type S,

nonreversing, Size 6, 540A, 400

HP at 460 VAC, up to 100 kA

SCCR, 3 phase, 3 pole, TeSys T,

480 VAC coil, open

8536SHO2V06H674

Main

Product Type

Motor starter

Product Range

S

Starter Type

Non reversing

Complementary

Nema Size

6

Rated Current

540 A

Number Of Poles

3P

Maximum Voltage Rating

600 V AC

Phase

3 phase

Type Of Overload

Solid state TeSys T

Horsepower Rating

150 HP 200 V AC

200 HP 230 V AC

400 HP 460 V AC

400 HP 575 V AC

Sccr

Circuit-breaker 800 A maximum: 65 kA at 480 V AC

Fuse J 600 A maximum: 100 kA at 600 V AC

Fuse T 600 A maximum: 100 kA at 600 V AC

Fuse RK1 600 A maximum: 100 kA at 600 V AC

Fuse RK5 600 A maximum: 100 kA at 600 V AC

Coil Voltage

440 V AC 50 Hz

480 V AC 60 Hz

Control Circuit Type

Common control circuit

Control Units

No control units

Pilot Light

Without pilot light

Auxiliary Contacts

Without

Terminal Type

Screw clamp terminals

Height

28.06 in (712.72 mm)

Width

12.34 in (313.44 mm)

Depth

9.00 in (228.60 mm)

Environment

Enclosure Type

Not rated (open device)

Certifications

UL Listed

CSA

NEMA

Product data sheet

Specifications

Feb 27, 2024

1
