3 / 13 page

Connector

Connection 1

Type

free cable end

Connection 2

Type

Socket straight 7/8"-16UNF

Number of positions

Coding type

Cable/line

Cable length

5 m

CMX-OUTDOOR-CMG [547]

Number of positions

Shielded

Cable type

CMX-OUTDOOR-CMG [547]

Conductor cross section

5 x AWG 18

External cable diameter

5.7 mm

Outer sheath, material

PVC

External sheath, color

yellow

Conductor material

Bare Cu litz wires

Single wire, color

black 1, blue 2, grey 3, brown 4, white 5

Nominal voltage, cable

300 V

Flame resistance

UL 1581, FT4

Other resistance

UV resistant (720 h) UL 2556

-40 °C ... 105 °C (cable, fixed installation)

Ambient temperature (operation)

-30 °C ... 105 °C (Cable, flexible installation)

Environmental and real-life conditions

Ambient conditions

Degree of protection

IP68

-20 °C ... 105 °C (Plug / socket)

-40 °C ... 105 °C (cable, fixed installation)

Ambient temperature (operation)

-30 °C ... 105 °C (Cable, flexible installation)

SAC-5P- 5,0-547/MINFS - Power cable

1416632

https://www.phoenixcontact.com/us/products/1416632

Jan 16, 2024, 6:51 AM

Page 3 (13)
