3 / 5 page ![]() 3 SY88822V Micrel, Inc. M9999-072505 hbwhelp@micrel.com or (408) 955-1690 Absolute Maximum Ratings(1) Power Supply Voltage (V CC) ............................ 0V to +7.0V Input Voltage (V IN) .............................................. 0V to VCC Output Current (I OUT) ................................................. 30mA Power Dissipation (P D) ........................................... 250mW Lead Temperature (soldering, 20 sec.) ................... +260 °C Storage Temperature Range (T S) ............ –55°C to +125°C Operating Ratings(2, 3, 4) Supply Voltage (V IN) ................................... +3.0V to +3.6V ........................................................ or +4.5V to +5.5V Ambient Temperature (T A), Note 5 ............ –40°C to +85°C Junction Temperature (T J), Note 5 ............ –40°C to 100°C Resistor to Dissipate Power (R EXT) .................. 10Ω to 50Ω Laser Diode Serial Resistor (R SER) .................... 0Ω to 50Ω Resistor to Adjust Current (R SET), Note 6 ......................................................... 700 Ω to 20,000Ω Package Thermal Resistance MSOP (θ JA) Still-Air ...................................................... 113°C/W (ψ JB) Still-Air ........................................................ 74°C/W GND = 0V; V CC = 3.3V ±10% or VCC = 5.0V ±10%; TA = –40°C to +85°C Symbol Parameter Condition Min Typ Max Units V IH Input HIGH Voltage V CC–1.165 V CC–0.880 V (D IN, /DIN, /EN) V IL Input LOW Voltage V CC–1.810 V CC–1.475 V (D IN, /DIN, /EN) V REF Reference Voltage 1.7 2.0 2.3 V I IL Input LOW Current V I = VIL(min) 0.5 µA (D IN, /DIN, /EN) I IH Input HIGH Current 100 µA (D IN, /DIN, /EN) I CC Supply Current I MOD = 25mA 25 mA I OUT_OFF Output LOW Current 450 1000 µA (/EN = HIGH) I OUT Modulation Current 30 mA A RSET I OUT/IRSET 30 38 44 — V OUT Voltage at OUT, /OUT V CC–1.4 V CC V C OUT Capacitance on OUT, /OUT 2.5 pF Notes: 1. Permanent device damage may occur if absolute maximum ratings are exceeded. This is a stress rating only and functional operation is not implied at conditions other than those detailed in the operational sections of this data sheet. Exposure to absolute maximum ratlng conditions for extended periods may affect device reliability. 2. The data sheet limits are not guaranteed if the device is operated beyond the operating ratings. 3. The device is guaranteed to meet the DC specifications, shown in the table above, after thermal equilibrium has been established. The device is tested in a socket such that transverse airflow of ≥500lfpm is maintained. 4. The voltage drop across REXT and RSER plus Laser Diode must not be greater than 1.4V. 5. Commercial devices are guaranteed from 0 °C to +85°C ambient temperature. 6. RSET minimum 430Ω. 7. Specification for packaged product only. DC ELECTRICAL CHARACTERISTICS(7) |
|
|
