LMV393

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

3 of 11

www.unisonic.com.tw

QW-R104-004,A

ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

2.7 ~ 5.0

Differential Input Voltage

VIN(DIFF)

±VCC

Voltage on any pin (referred to V- pin)

5.5

Junction Temperature

+150

°C

Operating Temperature

TOPR

-40 ~ +85

°C

Storage Temperature

TSTG

-65 ~ +150

°C

Note Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

THERMAL CHARACTERISTICS

PARAMETER

SYMBOL

RATINGS

UNIT

MSOP-8

190

DIP-8

100

Thermal Resistance Junction to Ambient

SOP-8

θJA

150

℃

DC ELECTRICAL CHARACTERISTICS (TJ=25℃, V-=0V, unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX UNIT

Input Offset Voltage

VIN(OFF)

1.7

Input Offset Voltage Average Drift

II(OFF)

μV/℃

Input Bias Current

II(BIAS)

100

250

Input Offset Current

II(OFF)

Input Voltage Range

VIN

-0.1

4.2

Supply Current

ICC

100

200

μA

Voltage Gain

V/mV

Saturation Voltage

VSAT

ISINK ≤4mA

200

400

2.7V

Output Sink Current

5.0V

ISINK

VOUT ≤1.5V

Output Leakage Current

ILEAK

0.003

μA

AC ELECTRICAL CHARACTERISTICS (TJ=25 ,

℃

RL=5.1kΩ, V-=0V, unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX UNIT

2.7V

5.0V

Input Overdrive=10mV

2.7V

3.8

Propagation Delay

(High to Low)

5.0V

tPHL

Input Overdrive=100mV

3.4

2.7V

5.0V

Input Overdrive=10mV

2.7V

0.7

Propagation Delay

(Low to High)

5.0V

tPLH

Input Overdrive=100mV

0.8
