LM339

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

www.unisonic.com.tw

QW-R104-001.D

ABSOLUTE MAXIMUM RATINGS (Ta=25°C)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

Vcc

+- 18 or 36

Differential input Voltage

VI(DIFF)

Input Voltage

VIN

-0.3~36

Power Dissipation

570

Junction Temperature

125

°C

Operating Temperature

TOPR

0 ~ +70

°C

Storage Temperature

TSTG

-40 ~ 150

°C

Note 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. The device is guaranteed to meet performance specification within 0℃ ~ 70℃ operating temperature range

and assured by design from –20℃ ~ +85℃.

ELECTRICAL CHARACTERISTICS

(Vcc=5.0V, Ta=25

°C, All voltage referenced to GND unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP.

MAX

UNIT

Input Offset Voltage

VI(OFF)

VCM=0 ~ Vcc-1.5

VOUT(p)=1.4V, Rs=0

+-1.5

+-5.0

Input Offset Current

II(OFF)

+-2.3

+-50

Input Bias Current

IBIAS

250

Input Common-Mode Voltage

Range

VIN(R)

Vcc-1.5

Supply Current

Icc

RL=∞

1.1

2.0

Large Signal Voltage Gain

Vcc=15V, RL>15kΩ

200

V/mV

Large Signal Response Time

tres

VIN=TTL logic wing

VREF=1.4V, VRL=5V, RL=5.1kΩ

350

Response Time

tres

VRL=5V, RL=5.1kΩ

1400

Output Sink Current

ISINK

VIN (-)>1V, VIN (+)=0V, VOUT(p)<1.5V

Output Saturation Voltage

VSAT

VIN (-)>1V, VIN (+)=0V, ISINK=4mA

140

400

Output Leakage Current

ILEAK

VIN (+)=1V,VIN (-)=0

VOUT(p)= 5V

VOUT (p)=30V

0.1

1.0

µA

Differential Input Voltage

VIN(DIFF)
