BA6220

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

3 of 5

www.unisonic.com.tw

QW-R109-001,B

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

18

V

DIP-8

1.4

W

Power Dissipation(note 1)

SOP-8

0.8

W

Operating Temperature

-25 ~ +75

°C

Storage Temperature

-55 ~ +125

°C

Note 1. PCB (Copper-surfaced) 9cm

2. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Operating Supply Voltage

Loader: 8g-cm

3.5

16

V

PARAMETER

SYMBOL

TEST

CIRCUIT

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Output Saturate Voltage

Fig.3

1.5

2.0

V

Reference Voltage

Fig.1

1.10

1.27

1.40

V

Current Ratio

K

Fig.2

18

20

22

Volatge Feature of

Reference Voltage

ΔV

Fig.1

Vcc=6.3 - 16V

0.06

%/V

Volatge Feature of

Current Ratio

ΔK/K/ΔV

CC

Fig.2

Vcc=6.3 - 16V

0.4

%/V

Bias Current

Fig.4

0.5

0.8

1.2

mA

Current Feature of

Reference Voltage

ΔV

Fig.1

-0.02

%/mA

Current Feature of

Current Ratio

ΔK/K/ΔI

M

Fig.2

-0.02

%/mA

Temperature Feature of

Reference Voltage

ΔV

Fig.1

Ta=-25 - 75

°C

0.01

%/

°C

Temperature Feature of

Current ratio

ΔK/K/ΔTa

Fig.2

Ta=-25 - 75

°C

0.01

%/

°C
