MECHANICAL DATA

MTSS003D – JANUARY 1995 – REVISED JANUARY 1998

POST OFFICE BOX 655303

DGG (R-PDSO-G**)

PLASTIC SMALL-OUTLINE PACKAGE

4040078 / F 12/97

48 PINS SHOWN

0,25

0,15 NOM

Gage Plane

6,00

6,20

8,30

7,90

0,75

0,50

Seating Plane

25

0,27

0,17

24

A

48

1

1,20 MAX

M

0,08

0,10

0,50

0

°–8°

56

14,10

13,90

48

DIM

A MAX

A MIN

PINS **

12,40

12,60

64

17,10

16,90

0,15

0,05

NOTES: A. All linear dimensions are in millimeters.

B. This drawing is subject to change without notice.

C. Body dimensions do not include mold protrusion not to exceed 0,15.

D. Falls within JEDEC MO-153
