1N6267A Series

http://onsemi.com

3

JEDEC

(Note 4)

(Note 5)

Breakdown Voltage

(Volts)

(

mA)

Min

Nom

Max

(mA)

(Volts)

(A)

(%/

°C)

1.5KE6.8A, G

1N6267A, G

5.8

1000

6.45

6.8

7.14

10

10.5

143

0.057

1.5KE7.5A, G

1N6268A, G

6.4

500

7.13

7.5

7.88

10

11.3

132

0.061

1.5KE8.2A, G

1N6269A, G

7.02

200

7.79

8.2

8.61

10

12.1

124

0.065

1.5KE9.1A, G

1N6270A, G

7.78

50

8.65

9.1

9.55

1

13.4

112

0.068

1.5KE10A, G

1N6271A, G

8.55

10

9.5

10

10.5

1

14.5

103

0.073

1.5KE11A, G

1N6272A, G

9.4

5

10.5

11

11.6

1

15.6

96

0.075

1.5KE12A, G

1N6273A, G

10.2

5

11.4

12

12.6

1

16.7

90

0.078

1.5KE13A, G

1N6274A, G

11.1

5

12.4

13

13.7

1

18.2

82

0.081

1.5KE15A, G

1N6275A, G

12.8

5

14.3

15

15.8

1

21.2

71

0.084

1.5KE16A, G

1N6276A, G

13.6

5

15.2

16

16.8

1

22.5

67

0.086

1.5KE18A, G

1N6277A, G

15.3

5

17.1

18

18.9

1

25.2

59.5

0.088

1.5KE20A, G

1N6278A, G

17.1

5

19

20

21

1

27.7

54

0.09

1.5KE22A, G

1N6279A, G

18.8

5

20.9

22

23.1

1

30.6

49

0.092

1.5KE24A, G

1N6280A, G

20.5

5

22.8

24

25.2

1

33.2

45

0.094

1.5KE27A, G

1N6281A, G

23.1

5

25.7

27

28.4

1

37.5

40

0.096

1.5KE30A, G

1N6282A, G

25.6

5

28.5

30

31.5

1

41.4

36

0.097

1.5KE33A, G

1N6283A, G

28.2

5

31.4

33

34.7

1

45.7

33

0.098

1.5KE36A, G

1N6284A, G

30.8

5

34.2

36

37.8

1

49.9

30

0.099

1.5KE39A, G

1N6285A, G

33.3

5

37.1

39

41

1

53.9

28

0.1

1.5KE43A, G

1N6286A, G

36.8

5

40.9

43

45.2

1

59.3

25.3

0.101

1.5KE47A, G

1N6287A, G

40.2

5

44.7

47

49.4

1

64.8

23.2

0.101

1.5KE51A, G

1N6288A, G

43.6

5

48.5

51

53.6

1

70.1

21.4

0.102

1.5KE56A, G

1N6289A, G

47.8

5

53.2

56

58.8

1

77

19.5

0.103

1.5KE62A, G

1N6290A, G

53

5

58.9

62

65.1

1

85

17.7

0.104

1.5KE68A, G

1N6291A, G

58.1

5

64.6

68

71.4

1

92

16.3

0.104

1.5KE75A, G

1N6292A, G

64.1

5

71.3

75

78.8

1

103

14.6

0.105

1.5KE82A, G

1N6293A, G

70.1

5

77.9

82

86.1

1

113

13.3

0.105

1.5KE91A, G

1N6294A, G

77.8

5

86.5

91

95.5

1

125

12

0.106

1.5KE100A, G

1N6295A, G

85.5

5

95

100

105

1

137

11

0.106

1.5KE110A, G

1N6296A, G

94

5

105

110

116

1

152

9.9

0.107

1.5KE120A, G

1N6297A, G

102

5

114

120

126

1

165

9.1

0.107

1.5KE130A, G

1N6298A, G

111

5

124

130

137

1

179

8.4

0.107

1.5KE150A, G

1N6299A, G

128

5

143

150

158

1

207

7.2

0.108

1.5KE160A, G

1N6300A, G

136

5

152

160

168

1

219

6.8

0.108

1.5KE170A, G

1N6301A, G

145

5

162

170

179

1

234

6.4

0.108

1.5KE180A, G

1N6302A, G*

154

5

171

180

189

1

246

6.1

0.108

1.5KE200A, G

1N6303A, G

171

5

190

200

210

1

274

5.5

0.108

1.5KE220A, G

185

5

209

220

231

1

328

4.6

0.109

1.5KE250A, G

214

5

237

250

263

1

344

5

0.109

Devices listed in bold, italic are ON Semiconductor Preferred devices. Preferred devices are recommended choices for future use and best overall value.

3. 1/2 sine wave (or equivalent square wave), PW = 8.3 ms, duty cycle = 4 pulses per minute maximum.

4. Indicates JEDEC registered data

greater than the dc or continuous peak operating voltage level.

7. Surge current waveform per Figure 5 and derate per Figures 1 and 2.

†The “G” suffix indicates Pb−Free package available.

*Not Available in the 1500/Tape & Reel
