background image
Data Sheet
ADMV1550
OUTLINE DIMENSIONS
©2023 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
One Analog Way, Wilmington, MA 01887-2356, U.S.A.
Rev. 0 | 34 of 34
4.10
4.00 SQ
3.90
2.449
2.399 SQ
2.349
0.707
0.626
0.545
1
6
9
10
14
18
15
5
TOP VIEW
SIDE VIEW
BOTTOM VIEW
PIN 1
INDICATOR
AREA
0.266
0.226
0.186
0.470
0.400
0.330
SEATING
PLANE
FOR PROPER CONNECTION OF
THE EXPOSED PADS, REFER TO
THE PIN CONFIGURATION AND
FUNCTION DESCRIPTIONS
SECTION OF THIS DATA SHEET.
2.50
REF
2.101
REF
0.70
BSC
0.55
BSC
0.75
REF
0.838
REF
0.275
REF
1.063
REF
0.35
REF
0.25 × 0.35
± 0.03
0.351
REF
Figure 123. 18-Terminal Land Grid Array [LGA]
(CC-18-2)
Dimensions shown in millimeters
Updated: August 09, 2023
ORDERING GUIDE
Model1
Temperature Range
Package Description
Packing Quantity
Package Option
ADMV1550ACCZ
−40°C to +85°C
18-Terminal Land Grid Array [LGA]
CC-18-2
ADMV1550ACCZ-R2
−40°C to +85°C
18-Terminal Land Grid Array [LGA]
Reel, 250
CC-18-2
1 Z = RoHS Compliant Part.
EVALUATION BOARDS
Table 8. Evaluation Boards
Model1
Description
ADMV1550-EVALZ
Evaluation Board
1 Z = RoHS-Compliant Part.
