ABSOLUTE MAXIMUM RATINGS (1)

VIN .................................................-0.3V to +37V

VCC, VGATE......................................-0.3V to +16V

VLED1 to VLED4.................................-0.3V to +80V

All other pins ................................-0.3V to +6.5V

Continuous power dissipation (TA = 25°C) (2)

TSSOP-16EP........................................... 2.78W

SOIC-16 ................................................... 1.56W

Junction temperature ................................150°C

Lead temperature .....................................260°C

Storage temperature ................ -60°C to +150°C

ESD Ratings

Human body model (HBM) ........................ ±2kV

Charged device model (CDM) ................. ±750V

Recommended Operating Conditions (3)

Supply voltage (VIN) ............................6V to 33V

Max LED current ................................. 400mA (5)

Operating junction temp........... -40°C to +125°C

Thermal Resistance (4)

θJA

θJC

TSSOP-16EP .........................45 ...... 10 ... °C/W

SOIC-16…………………………..80

……35....°C/W

Notes:

1) Exceeding these ratings may damage the device.

2) The maximum allowable power dissipation is a function of the

maximum junction temperature, TJ (MAX), the junction-to-

ambient thermal resistance,

θ

JA, and the ambient temperature,

TA. The maximum allowable continuous power dissipation at

any ambient temperature is calculated by PD (MAX) = (TJ

(MAX) - TA) / θJA. Exceeding the maximum allowable power

dissipation can produce an excessive die temperature, which

may cause the regulator to go into thermal shutdown. Internal

thermal shutdown circuitry protects the device from permanent

damage.

3) The device is not guaranteed to function outside of its operating

conditions.

4) Measured on JESD51-7, a 4-layer PCB.

5) Not tested in production. Guaranteed by characterization.
