E L E C T R O N I C S I N C .

Surface Mount Power Inductor

TEL: (818) 892-0761

FAX: (818) 894-5791

http://www.pca.com

PCA ELECTRONICS, INC.

16799 SCHOENBORN ST.

NORTH HILLS, CA 91343

• Low loss material ensures operation in high frequency

switching converters, such as Buck, Boost or as output

averaging filter inductor

• Also suitable for use in high quality filter applications

• 500 KHz Switching Frequency

EPI BHC68 Series

Product performance is limited to specified parameters. Data is subject to change without prior notice.

Package BHC68

Primary Specification

Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25

8.55

2.13

Inductance

(µH ± 15%)

@ 0 Idc

DCR

(

Ω Typ.)

.0114

.0028

Idc

(Amps)

11.2

22.4

Part

Number

EPI2L1223BHC68

Inductance

(µH ± 15%)

@ Odc

14.00

3.51

(V-µsec)

@ 500 KHz

6.4

3.2

Temp. Rise

(°C Typ.)

@ Vt1

CSIXXXXXXBHC88

Rev. 2

9/17/03

• Core Loss @ Ref. Vt : 83 mW •

1.00

Max.

(25.40)

.390

Max.

(9.91)

1.010

(25.65)

.620

(15.75)

.300

(7.62)

.080 (2.03)

.985/1.015

(25.02/25.78)

PCA

EPIXXXXXXBHC68

Suggested

Pad

Layout

Schematic

Series

Parallel

Connection

1.110 Max.

(28.19)
