ADL5519
Preliminary Technical Data
Rev. PrB | Page 22 of 27
Error (dB) =
(
)
Slope
P
P
Slope
V
Z
IN
OUT
−
×
−
where PZ is the x-axis intercept expressed in dBm. This is
analogous to the input amplitude that would produce an output
of 0 V, if such an output was possible.
Error from the linear response to the CW waveform is not a
measure of absolute accuracy, since it is calculated using the
slope and intercept of each device. However, it verifies the
linearity and the effect of modulation on the device’s response.
Similarly, error from 25°C performance uses the 25°C
performance of a given device and waveform type as the
reference from which all other performance parameters shown
alongside it are compared. It is predominantly (and most often)
used as a measurement of output variation with temperature.
