ATM13-12PD-R008 datasheet(3/3 Pages) ASS

3 / 3 page

2.00

10.00

82.55

4.00

3.00

101.60

6.35

2x 4.41

2x 9.00

12.00

KEEP CLEAR

BOTTOM SIDE

ONLY

2x 12.00

30.00

12x Ø1.2

+0.2

HOLE FOR

Ø1.04 PIN

2x Ø3.00

+0.2

FOR #4

[M3] SCREW

4.20

8.40

12.60

16.80

21.00

CIRCUIT BOARD HOLE LOCATIONS

AND KEEP CLEAR AREAS FOR

ATM13-12PX-R008

ATM13-12PX-GR01

ALL DIMENSIONS REFERENCE

TOP VIEW

2.45

REV

DESCRIPTION

DATE

REVISIONS

ECO

APPR

PROCESS SPECIFICATIONS:

MATERIAL SPECIFICATIONS:

QUANTITY

APPROVAL:

ENGINEER:

CHECKED:

DRAWN:

SCALE:

PART NUMBER

DWG NO:

TYPE

SHEET

DESCRIPTION

THIS DRAWING IS SUPPLIED FOR

INFORMATION ONLY. DESIGN FEATURES,

SPECIFICATIONS AND PERFORMANCE DATA

SHOWN HEREON ARE THE PROPERTY OF

THE AMPHENOL CORPORATION. NO RIGHTS

OF REPRODUCTION ARE IMPLIED. ALL

DIMENSIONS ARE SUBJECT TO NORMAL

MANUFACTURING VARIATIONS.

CUSTOMER:

NEXT ASS'Y:

44724 Morley Drive

Clinton Township, MI 48036

Sine Systems - www.amphenol-sine.com

ARMOR IPX RECEPTACLE ATM HEADER,

12 POSITIONS,SIZE 20 CONTACT

NONE

SEE SHEET 2

RELEASE NEW DRAWING

08JUN19

SULLEN TOMMY

2x 35.00

2.10

THREE DIMENSIONAL SPACE LIMIT

APPROXIMATE INTERNAL SPACE

FOR COMPONENT SPACE LAYOUT

MAX. COMPONENT HEIGHT UNDER BOARD 2.00 mm.

44.00

84.60

14.00

7.00

60.00

3D VIEW

AIPXE-325X4A-XXXX AND

AIPXE-325X4B-XXXX ENCLOSURE AND

MOUNTING HARDWARE SHOWN FOR REFERENCE

SECTION B-B

ASSEMBLED PCB ENCLOSURE

SHOWN FOR REFERENCE

SECTION A-A

(133)

HEADER

PCB

ENCLOSURE

#4 [M3] SCREW

LOCATION OPTIONAL

(17.6)

(19.2)

TOP SURFACE

OF PCB REF

UPDATE DRAWING

29JUL19

SULLEN TOMMY

11.00

19.00

17.00

22.00

2x4.00

UPDATED SPACE LIMIT DIMENSION

15JAN20

SULLEN TOMMY
