P9225-R Datasheet

© 2018 Integrated Device Technology, Inc.

33

November 12, 2018

14. Package Outline Drawings

The package outline drawings are appended at the end of this document and are accessible from the link below. The package information is

the most current data available and is subject to change.

www.idt.com/document/psc/ahg52-package-outline-2640-x-3940mm-body-04mm-pitch-dsbga

15. Special Notes: WLCSP-52 (AHG52) Package Assembly

Unopened dry packaged parts have a one-year shelf life.

The HIC indicator card for newly-opened dry packaged parts should be checked. If there is any moisture content, the parts must be baked for

a minimum of 8 hours at 125˚C within 24 hours of the assembly reflow process.

16. Marking Diagram

IDT

P9225

YYWW**

$-R

1. Line 1 company name.

2. Truncated part number.

3. “YYWW” is the last digit of the year and week that the part was assembled.

** is the lot sequential code.

4. “$” denotes mark code, -R is part of the device part number

17. Ordering Information

Orderable Part Number

Description and Package

MSL Rating

Carrier Type

Ambient

Temperature

P9225-RAHGI8

P9225-R Wireless Power Receiver for 5W Applications,

2.64 × 3.94 mm 52-WLCSP

MSL1

Reel

0°C to +85°C

P9225-R-EVK

P9225-R Evaluation Kit
