10

Package information

In order to meet environmental requirements, ST offers these devices in different grades of ECOPACK packages,

depending on their level of environmental compliance. ECOPACK specifications, grade definitions and product

status are available at: www.st.com. ECOPACK is an ST trademark.

10.1

SO-8 package information

Table 10. SO-8 package dimensions

Dim.

mm

Min.

Typ.

Max.

A

1.35

-

1.75

A1

0.10

-

0.25

b

0.35

-

0.49

c

0.19

-

0.25

D(1)

4.8

-

5

E1

3.8

3.9

4

E

5.8

6

6.2

e

1.27 BSC

L

0.4

-

1.25

h

0.25

-

0.50

θ

0°

7°

Θ1

2°

12°

aaa

0.25

bbb

0.25

ccc

0.1

1. Dimension “D” does not include mold flash, protrusions, or gate burrs. Mold flash, protrusions or gate burrs shall not exceed

0.15 mm per side.
