STM32U535NET3QTR datasheet(149/278 Pages) STMICROELECTRONICS

149 / 278 page

Table 47. Static power consumption of flash banks, when supplied by LDO/SMPS

Symbol

Parameter

Typ

Max(1)

Unit

25°C

55°C

85°C 105°C 125°C

25°C

55°C

85°C 105°C 125°C

IDD

(Flash_Bank1)

(2)

Flash bank 1 static consumption in normal mode

(PD1 = 1 versus PD1 = 0)

45.0

50.0

100.0

60.0

100.0 100.0

100.0

150.0

µA

IDD

(Flash_Bank2)

(2)

Flash bank 2 static consumption in normal mode

(PD2 = 1 versus PD2 = 0)

45.0

50.0

100.0

60.0

100.0 100.0

100.0

150.0

IDD

(Flash_Bank_LPM)

(3)

One flash bank additional static consumption in

normal mode versus low-power mode

(LPM = 0 versus LPM = 1)

25.0

50.0

40.0

70.0

1. Evaluated by characterization. Not tested in production.

2. When one bank is in power-down, this consumption is saved. When the flash memory is in power down in Sleep mode (SLEEP_PD =1 ), Bank 1 and Bank 2 are in

power down.

3. If no bank is in power-down, the flash memory additional static consumption in normal mode versus low-power mode is 2 x IDD(Flash_Bank_LPM).

Table 48. Current consumption in Stop 0 mode on LDO

Symbol

Parameter

Conditions

Typ

Max(1)

Unit

VDD (V)

25°C

55°C

85°C

105°C

125°C

25°C

55°C

85°C

105°C

125°C

IDD(Stop 0)

Supply current in Stop 0 mode,

regulator in Range 4,

RTC disabled,

8-Kbyte SRAM2 + ICACHE

retained

1.8

74.5

165

435

845

1600

230

500

1400

2600

4800

µA

2.4

74.5

165

435

845

1600

230

500

1400

2600

4800

3.0

74.5

165

440

845

1600

230

500

1400

2600

4800

3.3

75.0

165

440

850

1600

230

500

1400

2600

4800

3.6

76.0

170

440

850

1650

230

510

1400

2600

5000

Supply current in Stop 0 mode,

regulator in Range 4,

RTC disabled,

All SRAMs retained

1.8

79.0

175

465

905

1750

240

530

1400

2800

5300

2.4

79.0

175

465

910

1750

240

530

1400

2800

5300

3.0

79.0

175

465

910

1750

240

530

1400

2800

5300

3.3

79.5

175

465

910

1750

240

530

1400

2800

5300

3.6

80.5

180

470

915

1750

250

540

1500

2800

5300
