LSP5523

Absolute Maximum Ratings(at TA=25°C) (Note 4)

Note:

Operate over the “Absolute Maximum Ratings” may cause permanent damage to the device. Exposure to such conditions for

extended time may still affect the reliability of the device.

Characteristics

Value

Unit

Input Supply Voltage

-0.3 to 30

V

SW Voltage

-0.3 to VIN + 0.3

V

BS Voltage

VSW – 0.3 to VSW + 6

V

EN

-0.3 to 8

V

FB, COMP Voltage

-0.3 to 5

V

Continuous SW Current

Internally limited

A

Maximum Junction Temperature

150

°C

Storage Temperature Range

-65 to 150

°C

ESOP-8L Thermal Resistance(Junction to Case)

19

°C/W

ESOP-8L Thermal Resistance(Junction to Ambient)

84

°C/W

ESOP-8L Power dissipation

1450

mW

Moisture Sensitivity (MSL)

Please refer the MSL label on the IC package

bag/carton for detail

Note 4: Ratings apply to ambient temperature at 25°C.

Recommended Operating Conditions

Characteristics

Min

Max

Unit

Input Supply Voltage

4.5

27 (5)

V

Operating Junction Temperature

-20

+125 (6)

°C

Note 5: Operating the IC over this voltage is very easy to cause over voltage condition to VIN pin, SW pin, BS pin & EN pin.

Note 6: If the IC experienced OTP, then the temperature may need to drop to < 125 degree C to let the IC recover.
