LARA-R6 series - Data sheet

UBX-21004391 - R09

Electrical specifications

Page 31 of 41

C1-Public

Table 32 describes the maximum total internal capacitance and the maximum total internal

inductance, considering internal parts tolerance, provided by LARA-R6 series modules.

Module

Parameter

Description

Value

Unit

LARA-R6001

Maximum total internal capacitance

496

Maximum total internal inductance

9.8

LARA-R6401

Maximum total internal capacitance

493

Maximum total internal inductance

9.7

LARA-R6801

Maximum total internal capacitance

496

Maximum total internal inductance

9.7

Table 32: LARA-R6 series maximum total internal capacitance and maximum total internal inductance

Table 33 describes the maximum RF output power transmitted by LARA-R6 series modules from the

primary antenna (ANT1) pin as Power Class 4 Mobile Stations for GSM 850 / E-GSM 900 bands and/or

as Power Class 3 User Equipment for the LTE / UMTS bands.

Module

Parameter

Description

Value

Unit

LARA-R6001

ANT1 Pout

Maximum RF output power from ANT1 pin

33.5

dBm

LARA-R6401

ANT1 Pout

Maximum RF output power from ANT1 pin

24.0

dBm

LARA-R6801

ANT1 Pout

Maximum RF output power from ANT1 pin

33.5

dBm

Table 33: LARA-R6 series antenna pin (ANT1) maximum RF output power
