RJ11 Modular Cable Assemblies

Bel Part Number

Positions/Contacts

Straight/Reverse

Color

Lengths Available (XXX)

BC-64SSXXXF

6 position 4 contact

Straight

Silver

007 = 7ft

(XXX)

014 = 14ft

(XXX)

025 = 25ft

(XXX)

BC-64RSXXXF

6 position 4 contact

Reverse

Silver

007 = 7ft

(XXX)

014 = 14ft

(XXX)

025 = 25ft

(XXX)

RJ12 Modular Cable Assemblies

Bel Part Number

Positions/Contacts

Straight/Reverse

Color

Lengths Available (XXX)

BC-66SSXXXF

6 position 6 contact

Straight

Silver

007 = 7ft

(XXX)

014 = 14ft

(XXX)

025 = 25ft

(XXX)

BC-66RSXXXF

6 position 6 contact

Reverse

Silver

007 = 7ft

(XXX)

014 = 14ft

(XXX)

025 = 25ft

(XXX)

RJ45 Modular Cable Assemblies

Bel Part Number

Positions/Contacts

Straight/Reverse

Color

Lengths Available (XXX)

BC-88SS007F

8 position 8 contact

Straight

Silver

7ft

BC-88RS007F

8 position 8 contact

Reverse

Silver

7ft

Cable Catalog

Straight and Reverse Modular Cable Assemblies

BC = Cable Assembly Family

4 = 4 Contacts

6 = 6 Contacts

8 = 8 Contacts

F

XXX

BC

6

6 = 6 Position

8 = 8 Position

Position

Part Number

Contacts

S = Straight

R = Reverse

Straight/Reverse

4

F = Feet

UOM

S

007F = 7ft 014F = 14ft 025F = 25ft

Length

S

S = Silver

Color

Description

Bel’s modular cable offering also includes straight and reverse modular cable assemblies. RJ11, RJ12 and RJ45

configurations offer solutions for data and voice applications where high data transmission rates are not required.

Straight through wiring modular cable assemblies are commonly used for connections between modems, fax

machines, or other data applications. Reverse wiring cable assemblies are often used for voice applications. Bel’s

straight and reverse wired modular cable assemblies include 28 AWG conductors and gold-plated contacts to provide

clear transmission.

Straight Wiring Diagram

Reverse Wiring Diagram

Straight Wiring Diagram

Reverse Wiring Diagram

Straight Wiring Diagram

Reverse Wiring Diagram
