Fiber Optic Cable Assemblies

Description

Bel’s fiber optic cables are designed to be used in high flex environments due to the tight buffered cable design.

All of Bel’s fiber optic assemblies are built with Duplex fiber cable with PVC jackets. These fiber optic cables offer a

variety of single and multimode configurations for varying high-speed, high-bandwidth applications. Both single and

multimode assemblies are available at lengths of 1m, 2m, 3m, 4m and 5m. Single mode assemblies have a cable

diameter of 2.0mm and multimode assemblies have a cable diameter of 3.0mm. Color configurations are dependent

on end configurations. These cables are also backward compatible with legacy LANs.

LC to LC

Bel Part Number

Description

Type

Lengths Available (XXX)

LCLC-6DTPXXX

LC to LC, Orange Cable with Beige Boot MM, 62.5/125, OM1

010 = 1.0m

(XXX)

020 = 2.0m

(XXX)

030 = 3.0m

(XXX)

050 = 5.0m

(XXX)

LCLC-3DTPXXX

LC to LC, Aqua Cable with Aqua Boot

MM, 50/125, OM3

010 = 1.0m

(XXX)

020 = 2.0m

(XXX)

030 = 3.0m

(XXX)

050 = 5.0m

(XXX)

LCLC-SDTPXXX

LC to LC, Yellow Cable with Blue Boot

SM, 9/125, OM2

010 = 1.0m

(XXX)

020 = 2.0m

(XXX)

030 = 3.0m

(XXX)

050 = 5.0m

(XXX)

SC to LC

Bel Part Number

Description

Type

Lengths Available (XXX)

SCLC-6DTPXXX

SC to SC, Orange Cable with Beige Boot MM, 62.5/125, OM1

010 = 1.0m

(XXX)

020 = 2.0m

(XXX)

030 = 3.0m

(XXX)

050 = 5.0m

(XXX)

SCLC-3DTPXXX

SC to LC, Aqua Cable with Aqua Boot

MM, 50/125, OM3

010 = 1.0m

(XXX)

020 = 2.0m

(XXX)

030 = 3.0m

(XXX)

050 = 5.0m

(XXX)

SCLC-SDTPXXX

SC to LC, Yellow Cable with Blue Boot

SM, 9/125, OM2

010 = 1.0m

(XXX)

020 = 2.0m

(XXX)

030 = 3.0m

(XXX)

050 = 5.0m

(XXX)

SC to SC

Bel Part Number

Description

Type

Lengths Available (XXX)

SCSC-6DTPXXX

SC to SC, Orange Cable with Beige Boot MM, 62.5/125, OM1

010 = 1.0m

(XXX)

020 = 2.0m

(XXX)

030 = 3.0m

(XXX)

050 = 5.0m

(XXX)

SCSC-SDTPXXX

SC to SC, Yellow Cable with Blue Boot

SM, 9/125, OM2

010 = 1.0m

(XXX)

020 = 2.0m

(XXX)

030 = 3.0m

(XXX)

050 = 5.0m

(XXX)

ST to ST

Bel Part Number

Description

Type

Lengths Available (XXX)

STST-6DTPXXX

ST to ST, Orange Cable with Beige Boot MM, 62.5/125, OM1

010 = 1.0m

(XXX)

020 = 2.0m

(XXX)

030 = 3.0m

(XXX)

050 = 5.0m

(XXX)
