198

145 Algonquin Parkway, Whippany, NJ 07981 • 973-560-0019 • FAX: 973-560-0076

e-mail: sales@powerdynamics.com •

www.powerdynamics.com

S - I B - H

I.D.C.

PDI -

NUMBER OF PINS:

= 09

= 15

= 25

= 37

GENDER:

MALE

= S

FEMALE

= R

MATING FACE:

= BLANK

= H

= R

4-40 THREADED RIVET

HOLE

4-40 THREADED RIVET AND JACK SCREW

GOLD PLATING:

(XX is gold in micro inches)

= GXX

GOLD FLASH (STANDARD)

= BLANK

EXAMPLE & ORDERING CODE

ELECTRICAL SPECIFICATIONS:

Rated Current: 3A

Rated Voltage: 300 VDC

Insulator Resistance:

3000 Megaohm min. @ 500 VDC

Contact Resistance: 15 milliohm max.

Dielectric Withstanding Strength:

1000 VAC for 1 minute

Temperature: -55

°C to 105°C

MATERIAL AND FINISH:

Shell:

Material:

Steel

Plating:

Tin

Thickness:

Base Copper: 40

µ"

Tin: 80~120

µ"

Contacts:

Material:

Brass (male)

Phosphor Bronze (female)

Plating:

Gold Plate and Tin/Lead over Nickel

Thickness:

Gold Flash

µ" Nickel base

80~100

µ" Tin/Lead

Insulator:

P.B.T. and glass-fiber reinforced

UL 94V-0

Mechanical:

Mating Force: 9 PIN 15 PIN 25 PIN 37 PIN

minimum: 1.5 kg 2.0 kg

3.0 kg 3.0 kg

maximum: 5.0 kg 7.0 kg

8.0 kg 12.0 kg

Unmating Force: 9 PIN 15 PIN 25 PIN 37 PIN

minimum: 1.5 kg 2.0 kg

3.5 kg 3.5 kg

maximum: 5.0 kg 7.0 kg

8.0 kg 12.0 kg

SPECIFICATIONS
