440L Series

www.vishay.com

Vishay Cera-Mite

Revision: 29-Oct-2021

Document Number: 23102

For technical questions, contact: ceramitesupport@vishay.com

THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT

ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000

WIRE LEAD OPTIONS - BULK PACKAGED

Radial leaded capacitors may be ordered with various wire lead options by adding appropriate suffix code to the catalog part

number.

Example: 440LD22UG-R (suffix code) specifies:

#20 AWG wire; LS = 0.375"; inline wire; long lead length, bulk packed

Notes

• Popular wire lead form options are described above; consult factory for other available forms www.vishay.com/doc?23140

• Practical consideration may limit wire options depending on capacitor size - verify special requirements with factory

• For detailed information and figures see general information: www.vishay.com/doc?23140

Fig. 1 - Straight wire

Fig. 2 - Inline wire

TAPE AND REEL OPTIONS

Radial leaded parts may be ordered with tape and reel packaging by adding appropriate suffix code to part number, like for wire

lead options.

Note

(1) Figure can be found in general information www.vishay.com/doc?23140, section Tape and Reel Options

WIRE FORM

DESCRIPTION

FIG.

LEAD

LENGTH

LEAD SPACING

0.375" (9.5 mm)

0.400" (10.0 mm)

0.500" (12.7 mm)

#20

AWG

#22

AWG

#20

AWG

#22

AWG

#20

AWG

#22

AWG

Straight wire

Long “LL”

Inline wire

Long “LL”

Cut “CL”

0.125" (3.2 mm) max.

max.

0.187" (4.8 mm) max.

max.

Minimum CL = 0.120" (3 mm) inline wire, LO = 0

WIRE INFORMATION

#20 AWG

0.032" (0.81) tinned copper wire

#22 AWG

0.025" (0.64) tinned copper wire

LEAD LENGTH INFORMATION

• Standard long lead “LL” length = 1.250" (32 mm) minimum

• Cut lead “CL” length may be user specified; if unspecified, Vishay Cera-Mite supplies 0.187" (4.8 mm) EIA standard

• Cut lead lengths are measured from bottom of wire seating plane (wire support point on circuit board)

• Cut lead length tolerance: + 0.031" / - 0.015" (+ 0.8 mm / - 0.4 mm)

TAPE AND REEL PACKAGING PART NUMBER SUFFIX

TAPE AND REEL SUFFIX CODES FOR VARIOUS WIRE FORMS AND SIZES

TAPE AND REEL

FIG.

(mm)

MAX. DISC

DIAMETER

TAPE AND REEL

STANDARD

STRAIGHT WIRE

FIG. 1

INLINE WIRE

FIG. 2

(in)

(mm)

#20

AWG

#22

AWG

#20

AWG

#22

AWG

C (1)

0.708

18.0

EIA
