CD Series

8mm DIP Coded Rotary Switches

CONTACT MATERIAL

.335

(8,5)

.630

(16,0)

.403

(10,2)

.079

(2,0)

.157

(4,0)

.059 DIA

(1,5Ø)

.069

(1,8)

.945

(24,0)

.194

(4,9)

FEED DIRECTION

For part number CDxxM0SB

Reel Information

Outside diameter

13.00 (333,0)

Pilot hole

.512 (13,0)

TAPE & REEL

OPTION

CODE

CONTACT

MATERIAL

TERMINAL

PLATING

RATING

RoHS

COMPLIANT*

RoHS

COMPATIBLE*

GOLD

GOLD

B

0.4 VC MAX. @ 20 V AC or DC MAX.

YES

YES

LOW LEVEL/DRY CIRCUIT
