CC400

SWRS050

Page 4 of 32

Absolute Maximum Ratings

The absolute maximum ratings given in Table 1 must under no circumstances be violated.

Stress exceeding one or more of the limiting values may cause permanent damage to the

device.

Parameter

Min.

Max.

Units

Condition

Supply voltage, VDD

-0.3

7.0

Voltage on any pin

-0.3

VDD+0.3,

max 7.0

Input RF level

dBm

Storage temperature range

-50

150

°C

Reflow solder temperature

260

°C

T = 10 s

Table 1: Absolute Maximum Ratings

Caution!

ESD

sensitive

device.

Precaution should be used when handling

the device in order to prevent permanent

damage.

Operating Conditions

The operating conditions for

CC400 are listed in Table 2 below.

Parameter

Min.

Max.

Units

Condition

Operating ambient temperature

-30

°C

Table 2: Operating Conditions

Electrical Specifications

Tc = 25°C, VDD = 3.0V if nothing else stated. Measured on Chipcon’s

CC400DB reference

design.

Parameter

Min.

Typ.

Max.

Unit

Condition

Supply voltage

2.7

3.0

3.3

Recommended operation voltage

Operating limits

Current Consumption,

receive mode

Current Consumption,

average in receive mode using

polling

230

µA

1:100 receive to power down ratio

Current Consumption,

transmit mode:

P=1 mW (0 dBm)

P=4 mW (6 dBm)

P=10 mW (10 dBm)

P=20 mW (13 dBm)

P=25 mW (14 dBm)

The output power is delivered to

a 50

Ω load

Current Consumption,

Power Down

0.2

µA

Oscillator core on

Oscillator core off

Table 3: Electrical Specifications
