Data Sheet

ADCA5190

TABLE OF CONTENTS

analog.com

Rev. 0 | 2 of 22

Features................................................................ 1

Applications........................................................... 1

Functional Block Diagram......................................1

General Description...............................................1

Specifications ....................................................... 3

General Downstream Performance....................3

Distortion Data....................................................4

Absolute Maximum Ratings...................................5

Thermal Resistance .......................................... 5

Electrostatic Discharge (ESD) Ratings...............5

ESD Caution.......................................................5

Pin Configuration and Function Descriptions........ 6

Typical Performance Characteristics..................... 7

S-Parameters for Downstream Application

(See Figure 31)................................................ 7

DOCSIS 4.0 Downstream Performance

(See Figure 31)................................................ 8

DOCSIS 3.1 Downstream Performance

(See Figure 31)...............................................11

Noise Performance ..........................................13

Theory of Operation ............................................14

Applications Information...................................... 15

Thermal Considerations................................... 15

Soldering Information and Recommended

PCB Land Pattern.......................................... 15

Supply Voltage and Bias Current .................... 16

Downstream Applications Circuit with

Passive Biasing.............................................. 17

Downstream Cable Application Circuit with

Passive Biasing Bill of Materials.....................18

Downstream Applications Circuit with Active

Biasing............................................................19

Downstream Cable Application Circuit with

Active Biasing Bill of Materials....................... 20

Layout Considerations......................................21

Outline Dimensions............................................. 22

Ordering Guide.................................................22

Evaluation Boards............................................ 22

REVISION HISTORY

7/2022—Revision 0: Initial Version
