STS2DPF80

DUAL P-CHANNEL 80V - 0.21

Ω - 2.3A SO-8

STripFET™ POWER MOSFET

Rev.0.1

■

TYPICAL RDS(on) = 0.21

Ω

■

STANDARD OUTLINE FOR EASY

AUTOMATED SURFACE MOUNT ASSEMBLY

DESCRIPTION

This application specific Power MOSFET is the

second generation of STMicroelectronis unique

"Single Feature Size™" strip-based process. The

resulting transistor shows extremely high packing

density for low on-resistance, rugged avalanche

characteristics and less critical alignment steps

therefore a remarkable manufacturing reproduc-

ibility.

APPLICATIONS

■

DC/DC CONVERTERS

■

BATTERY MANAGEMENT IN NOMADIC

EQUIPMENT

■

POWER MANAGEMENT IN CELLULAR

PHONES AND DISPLAY NEW GENERATION

Ordering Information

TYPE

VDSS

RDS(on)

ID

STS2DPF80

80 V

<0.25

Ω

2.3 A

SALES TYPE

MARKING

PACKAGE

PACKAGING

STS8DPF80

S8DPF80

SO-8

TAPE & REEL

SO-8

ABSOLUTE MAXIMUM RATINGS

(

•) Pulse width limited by safe operating area.

Note: For the P-CHANNEL MOSFET actual polarity of voltages and

current has to be reversed

Symbol

Parameter

Value

Unit

VDS

Drain-source Voltage (VGS = 0)

80

V

VDGR

Drain-gate Voltage (RGS = 20 k

Ω)

80

V

VGS

Gate- source Voltage

± 20

V

ID

Drain Current (continuous) at TC = 25°C Single Operation

Drain Current (continuous) at TC = 100°C Single Operation

2.0

1.3

A

IDM(

•)

Drain Current (pulsed)

8

A

Ptot

Total Dissipation at TC = 25°C

2.5

W

Tstg

Storage Temperature

-55 to 150

°C

Tj

Max. Operating Junction Temperature

150

°C

INTERNAL SCHEMATIC DIAGRAM
