22 / 23 page

ADL6010

Data Sheet

Rev. E | Page 22 of 23

OUTLINE DIMENSIONS

1.70

1.60

1.50

0.425

0.350

0.275

TOP VIEW

SIDE VIEW

0.35

0.30

0.25

BOTTOM VIEW

0.60

0.55

0.50

1.10

1.00

0.90

0.20 REF

0.05 MAX

2.10

2.00 SQ

1.90

0.65 BSC

EXPOSED

PAD

FOR PROPER CONNECTION OF

THE EXPOSED PAD, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET.

SEATING

PLANE

P IN 1

IN D IC AT O R AR E A OP T IO N S

(SEE DETAIL A)

PIN 1

INDICATOR

AREA

COPLANARIT Y

0.08

0.15 MIN

DETAIL A

(JEDEC 95)

Figure 50. 6-Lead Lead Frame Chip Scale Package [LFCSP]

2.00 mm × 2.00 mm Body and 0.55 mm Package Height

(CP-6-7)

Dimensions shown in millimeters

1.230

0.630

0.155

0.196

0.124

0.185

0.061

0.305

SIDE VIEW

0.185

0.122

0.066 × 0.137

(Pads 1, 4, 6)

0.066 × 0.157

TOP VIEW

(CIRCUIT SIDE)

0.846

0.620

0.107

0.089

0.086

0.066 × 0.066

0.069 × 0.066

Figure 51. 6-Pad Bare Die [CHIP]

(C-6-14)

Dimensions shown in millimeters
