ADP1764

Data Sheet

Rev. A | Page 10 of 20

CH1 50mV

CH3 2A

4.00µs

5GS/s

1M points

CH3

2.48A

11.24000µs

IOUT

VOUT

SLEW RATE = 4A/µs

Figure 22. Load Transient Response, COUT = 22 μF, VIN = 1.4 V, VOUT = 0.9 V

CH1 50mV

CH3 2A

4.00µs

5GS/s

1M points

CH3

2.48A

11.32000µs

IOUT

VOUT

SLEW RATE = 4A/µs

Figure 23. Load Transient Response, COUT = 47 μF, VIN = 1.4 V, VOUT = 0.9 V

CH1 2mV

CH2 500mV

4.00µs

5GSPS

1M POINTS

CH2

1.86V

9.020000µs

VIN

VOUT

Figure 24. Line Transient Response, Load Current = 4 A,

VIN = 1.6 V to 1.98 V Step, VOUT = 1.3 V

CH1 2mV

CH3 500mV

4.00µs

5GS/s

1M points

CH2

1.53V

9.020000µs

VIN

VOUT

Figure 25. Line Transient Response, Load Current = 4 A,

VIN = 1.3 V to 1.7 V Step, VOUT = 0.9 V

4.0

0.5

1.5

2.5

3.5

1.0

2.0

3.0

0.1

LOAD CURRENT (A)

10Hz TO 100kHz

100Hz TO 100kHz

Figure 26. Output Noise vs. Load Current (ILOAD)

0.5

0.7

0.9

1.1

1.3

1.5

OUTPUT VOLTAGE (V)

4.0

0.5

1.5

2.5

3.5

1.0

2.0

3.0

10Hz TO 100kHz

100Hz TO 100kHz

Figure 27. Output Noise vs. Output Voltage (VOUT)
