background image
EM62100
65 COM/132 SEG STN LCD Driver
18 •
•••
Product Specification (V1.1) 09.13.2005
(This specification is subject to change without further notice)
When several EM62100 chips are used, the slave chips must supply the display timing
signals (M, CK, DOFB) from the master chip. Explanation is shown in Table 6.
Table 6
Operating Mode
M
CK
DOFB
Master (M/S= “H”) The internal oscillator circuit is enabled (CKS=”H”)
The internal oscillator circuit is disabled (CKS=”L”)
O
O
O
I
O
O
Slave (M/S = “L”) The internal oscillator circuit is enabled (CKS=”H”)
The internal oscillator circuit is disabled (CKS=”L”)
I
I
I
I
I
I
O: Output, I: Input
NOTE
When the EM62100 is used in the master/slave configuration, each of the CKS pins
are set to the same level together.
Table 7 shows the relationship between the oscillation frequency and frame frequency.
fOSC which can be selected as 31.4 or 26.3kHz by using Oscillation Frequency Select
command.
Table 7
Duty
Item
fCK
fM
On-chip oscillator is used
fOSC/6
fCK / (2 x 65)
1/65
On-chip oscillator is not used
External input fCL
fCK / (2 x 65)
On-chip oscillator is used
fOSC/7
fCK / (2 x 55)
1/55
On-chip oscillator is not used
External input fCL
fCK / (2 x 55)
On-chip oscillator is used
fOSC/8
fCK / (2 x 49)
1/49
On-chip oscillator is not used
External input fCL
fCK / (2 x 49)
On-chip oscillator is used
fOSC/12
fCK / (2 x 33)
1/33
On-chip oscillator is not used
External input fCL
fCK / (2 x 33)
On-chip oscillator is used
fOSC/22
fCK / (2 x 17)
1/17
On-chip oscillator is not used
External input fCL
fCK / (2 x 17)
On-chip oscillator is used
fOSC/44
fCK / (2 x 9)
1/9
On-chip oscillator is not used
External input fCL
fCK / (2 x 9)
