Distribution block - PTFIX 2X4 RD - 1028362

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Distribution block, Basic terminal block, nom. voltage: 450 V, nominal current: 32 A, connection method:

Push-in connection, number of connections: 2, cross section: 0.2 mm² - 6 mm², AWG: 24 - 10, width: 6.2 mm,

height: 21.7 mm, color: red, mounting type: for snapping onto a DIN rail adapter

Key Commercial Data

Packing unit

50 pc

Minimum order quantity

50 pc

GTIN

GTIN

4055626526928

Technical data

General

Number of levels

1

Number of connections

2

Nominal cross section

4 mm²

Color

red

Insulating material

PA

Flammability rating according to UL 94

V0

Maximum load current

41 A

32 A

450 V

Open side panel

No

Ambient temperature (operation)

-60 °C ... 85 °C

Ambient temperature (storage/transport)

-25 °C ... 55 °C (For a short time, not exceeding 24 h, -60 to +70 °C)

Permissible humidity (storage/transport)

30 % ... 70 %

Ambient temperature (assembly)

-5 °C ... 70 °C

Ambient temperature (actuation)

-5 °C ... 70 °C

Shock protection test specification

DIN EN 50274 (VDE 0660-514):2002-11
