ams Datasheet

Page 1

[v2-01] 2017-Jul-13

Document Feedback

AS5045

12-Bit Programmable Magnetic Rotary

Position Sensor

The AS5045 is a contactless magnetic position sensor for

accurate angular measurement over a full turn of 360°. It is a

system-on-chip, combining integrated Hall elements, analog

front end and digital signal processing in a single device.

To measure the angle, only a simple two-pole magnet, rotating

over the center of the chip, is required. The magnet may be

placed above or below the IC.

The absolute angle measurement provides instant indication of

the magnet’s angular position with a resolution of

0.0879° = 4096 positions per revolution. This digital data is

available as a serial bit stream and as a PWM signal.

An internal voltage regulator allows the AS5045 to operate at

either 3.3 V or 5 V supplies.

Ordering Information and Content Guide appear at end of

datasheet.

Key Benefits & Features

The benefits and features of AS5045, 12-Bit Programmable

Magnetic Rotary Position Sensor are listed below:

Figure 1:

Added Value of Using AS5045

• Two digital 12-bit absolute outputs:

• Serial interface and

• Pulse width modulated (PWM) output

• Failure detection mode for magnet placement monitoring

and loss of power supply

• “Red-Yellow-Green” indicators display placement of magnet

in Z-axis

Benefits

Features

• Highest reliability and durability in harsh

environments

• Contactless absolute angle position measurement

• Great flexibility during assembly

• User programmable zero position

• Operation safety

• Diagnostic modes for magnet detection and power supply

loss

• Lower material cost (no magnetic

shielding needed)

• Immune to external magnetic stray fields

General Description
