35 / 69 page  NXP Semiconductors ASL5xxxyHz Matrix LED Controller (MLC) ASL5xxxyHz All information provided in this document is subject to legal disclaimers. © NXP B.V. 2019. All rights reserved. Product data sheet Rev. 2.1 — 5 February 2019 35 / 69 Command CMD[10:5] Type Description PWM Mode (Smart / Direct) CAN/CAN -FD CAN Valid DLC CAN-FD Valid DLC Other Invalid conditions 22 Invalid command 23 Invalid command 24 Invalid command 25 Invalid command 26 Invalid command 27 Invalid command 28 Invalid command 29 Invalid command 30 Selective MTP read All All 2 2 LHM mode || MTP_Locked || Invalid Key 31 Invalid command 32 Broadcast MLC channel start All All 2 2 LHM mode 33 Broadcast MLC channel immediate OFF All All 2 2 LHM mode 34 Broadcast Dummy trimming All All 0 0 NA 35 Broadcast POK register read All All 0 0 NA 36 Broadcast POR register read All All 0 0 NA 37 Broadcast LHM refresh All All 1 1 NA 38 Broadcast LHM exit All All 3 3 NA 39 Broadcast Clear all OC/ SC flags All All 0 0 NA 40 Broadcast Diagnosis read All All 0 0 NA 41 Broadcast Go to sleep All All 0 0 LHM mode || Partial networking enabled 42 Broadcast Partial sleep All All 4 4 LHM mode || partial networking disabled 43 Broadcast Partial wake All All 4 4 LHM mode || partial networking disabled || Not in Sleep mode 44 Broadcast Write all PWM registers of all MLCs Direct CAN-FD NA 12 LHM mode 45 Broadcast Read smart PWM feedback Smart All 0 0 NA 46 Broadcast Diagnosis ADC trigger All All 0 0 NA 47 Invalid command 48 Invalid command 49 Invalid command 50 Invalid command |
|
