Optical reading head

PCV80-F200-R4-V19

2

General

The reading head is part of the positioning system in the method for measurement by Pep-

perl+Fuchs. It consists of a camera module and an integrated illumination unit among other

things. The reading head detects position marks, which are put on an adhesive code band in

the form of Data Matrix code. The mounting of the code band is as a rule stationary on a firm

part of the plant (elevator shaft, overhead conveyor mounting rails…); that of the reading head

is parallel on the moving "vehicle" (elevator car, overhead conveyor chassis…).

Dimensions

Electrical Connection

Pinout

7

1

2

3

4 5

6

8

38.5

70

14.5

1

2

1

2

3

4

5

6

7

8

OUT 2 / IN 2

+ UB

Data+ / TX / 485+

Data- / RX / 485-

OUT 1

IN 1

GND

OUT 3 / IN 3

1

4

6

7

8

5

3

2

Additional Information

Accessories

PCV-USB-RS485-Converter Set

USB to RS 485 interface converter

PCV-KBL-V19-STR-RS485

Cable unit with power supply for USB / RS-

485 interface converter

V19-G-ABG-PG9

Female connector, M12, 8-pin, shielded,

field attachable

V19-G-ABG-PG9-FE

Female connector, M12, 8-pin, shielded,

field attachable

PCV-SC12

Grounding clip for PCV system

PCV-LM25

Marker head for 25 mm code tape

PCV-AG80

Alignment guide for PCV80-* read head

PCV-MB1

Mounting bracket for PCV* read head

Vision Configurator

Operating software for camera-based

sensors

ADJUST

CONFIG

1

2

LED

1

2

3

4

5

6

7
