IO-Link master (EIP/MOD)

ICE2-8IOL-K45S-RJ45

EtherNet/IP IO-Link master with 8 inputs/outputs, DIN rail, screw terminal

Function

The module is an EtherNet/IP fieldbus module with 8 type A IO-Link master ports according to the IO-Link standard V1.1.

The fieldbus module serves as an interface between the controller of a EtherNet/IP fieldbus system and IO-Link devices at the field level.

The integrated web server and IODD interpreter enables complete configuration of the fieldbus module and attached IO-Link devices

without the need for special software tools. Information regarding the status of the module is also displayed and network parameters

such as the IP address and subnet mask can be configured. The module is capable of storing all configuration enabling stand-alone usage without

a higher-level PLC. MutliLink simultaneously provides data access via different communication protocols like EtherNet/IP, Modbus/TCP and OPC

UA to multiple controllers. A screw terminal connector is used for supplying power that enables a current rating of up to 3.7 A.

The inputs and outputs are equipped with screw terminal connectors. Connection to the fieldbus is achieved using a standard

RJ45 Ethernet connector.

Status information for each channel is displayed via LEDs as a diagnostic function.

Dimensions

45.2

113.6

1
