Low Phase Noise PECL VCXO (100MHz to 200MHz)

47745 Fremont Blvd., Fremont, California 94538 TEL (510) 492-0990 FAX (510) 492-0991 [www.phaselink.com]

Rev 7/28/04 Page 6

PACKAGE INFORMATION

ORDERING INFORMATION

PhaseLink Corporation, reserves the right to make changes in its products or specifications, or both at any time without notice. The information

furnished by Phaselink is believed to be accurate and reliable. However, PhaseLink makes no guarantee or warranty concerning the accuracy of said

information and shall not be responsible for any loss or damage of whatever nature resulting from the use of, or reliance upon this product.

LIFE SUPPORT POLICY: PhaseLink’s products are not authorized for use as critical components in life support devices or systems

without the express written approval of the President of PhaseLink Corporation.

PART NUMBER

The order number for this device is a combination of the following:

Device number, Package type and Operating temperature range

P521-23

D C

Order Number

Marking

Package Option

P521-23DC

P521-23DC

Die – Waffle Pack

P521-23OC-R

P521-23 OC

TSSOP – Tape and Reel

P521-23OC

P521-23 OC

TSSOP – Tube

PART NUMBER

TEMPERATURE

C=COMMERCIAL

C

L

A

16 PIN Narrow SOIC, TSSOP ( mm )

SOIC

TSSOP

Symbol

Min.

Max.

Min.

Max.

A

1.35

1.75

-

1.20

A1

0.10

0.25

0.05

0.15

B

0.33

0.51

0.19

0.30

C

0.19

0.25

0.09

0.20

D

9.80

10.00

4.90

5.10

E

3.80

4.00

4.30

4.50

H

5.80

6.20

6.40 BSC

L

0.40

1.27

0.45

0.75

e

1.27 BSC

0.65 BSC

E

H

D

A1

e

B

PACKAGE TYPE

D=Die

O=TSSOP
