i.MX RT1170 Crossover Processors Data Sheet for Consumer Products, Rev. 1, 05/2021

NXP Semiconductors

i.MX RT1170 introduction

Ensure to have the proper data sheet for specific part by verifying the temperature grade (junction) field

and matching it to the proper data sheet. If there are any questions, visit the web page nxp.com/IMXRT or

contact an NXP representative for details.

Figure 1. Part number nomenclature—i.MX RT11XX family

Temperature (Tj)

Consumer: 0 to + 95 °C

Industrial: -40 to +105 °C

Extended Industrial: -40 to + 125

Automotive: -40 to + 125

Main Core Frequency

2xx MHz

500 MHz

600 MHz

800 MHz

1 GHz

Qualification Level

Prototype Samples

Mass Production

Special

Part # series

i.MX RT

IMX

X X

Family

First Generation RT family

Reserved

2-8

Silicon Rev

Sub-Family

RT116x

RT117x

RT118x

Package Type

289MAPBGA, 14 x 14 mm, 0.8 mm pitch

196MAPBGA, 12 x 12 mm, 0.8 mm pitch

144MAPBGA, 10 x 10 mm, 0.8 mm pitch

Tie

Single Core Standard Feature

Single Core Enhanced Feature

Dual Core Enhanced Security

Dual Core Standard Feature

Dual Core Enhanced Feature

Dual Core Premium Feature

Dual Core Full Feature

Facial Recognition

Hybrid Solution with Vision & Voice

Local Voice Control (text input models)
