background image
Data Sheet
HMC773ALC3B
Rev. F | Page 3 of 22
SPECIFICATIONS
ELECTRICAL SPECIFICATIONS
TA = 25°C, IF = 500 MHz, LO drive = 13 dBm, RF frequency range = 6.0 GHz to 16.0 GHz, all measurements performed as a
downconverter with the upper sideband selected, unless otherwise noted.
Table 1.
Parameter
Symbol
Min
Typ
Max
Unit
FREQUENCY RANGE
Radio Frequency
RF
6
16
GHz
Local Oscillator
LO
6
16
GHz
Intermediate Frequency
IF
dc
8
GHz
CONVERSION LOSS
9
12
dB
NOISE FIGURE
10
dB
ISOLATION
LO to RF
33
37
dB
LO to IF
30
37
dB
RF to IF
11
15
dB
INPUT THIRD-ORDER INTERCEPT
IP3
11
17
dBm
INPUT SECOND-ORDER INTERCEPT
IP2
45
dBm
INPUT POWER
1 dB Compression
P1dB
10
dBm
RETURN LOSS
RF Port
12
dB
LO Port
12
dB
TA = 25°C, IF = 500 MHz, LO drive = 13 dBm, RF frequency range = 16.0 GHz to 26.0 GHz, all measurements performed as a
downconverter with the upper sideband selected, unless otherwise noted.
Table 2.
Parameter
Symbol
Min
Typ
Max
Unit
FREQUENCY RANGE
Radio Frequency
RF
16
26
GHz
Local Oscillator
LO
16
26
GHz
Intermediate Frequency
IF
dc
8
GHz
CONVERSION LOSS
9
14
dB
NOISE FIGURE
12
dB
ISOLATION
LO to RF
33
37
dB
LO to IF
32
37
dB
RF to IF
15
20
dB
INPUT THIRD-ORDER INTERCEPT
IP3
16
20
dBm
INPUT SECOND-ORDER INTERCEPT
IP2
50
dBm
INPUT POWER
1 dB Compression
P1dB
10
dBm
RETURN LOSS
RF Port
10
dB
LO Port
12
dB
