MODEL: R1M-D1

R1M-D1 SPECIFICATIONS

ES-5659 Rev.12 Page 7/10

https://www.m-system.co.jp/

■ INPUT REGISTERS DESCRIPTION

(1) ANALOG INPUT IN % (30001 to 30016; 30001 to 30008 for J3)

Indicates analog input values in percentage for each channel (1 – 16; 1 – 8 for J3).

INPUT TYPE & RANGE

A/D DATA (Decimal)

DC

±20V

±20000

±5V

±5000

±1V

±10000

±0.8V

±8000

±0.2V

±20000

±50mV

±5000

±10mV

±10000

Thermocouple

Temperature x 10

RTD

Temperature x 10

Potentiometer

0 – 100Ω

0 – 500Ω

0 – 1kΩ

0 – 10kΩ

±2000

(2) ANALOG INPUT IN ENGINEERING UNIT (30017 to 30048; 30017 to 30032 for J3)

Indicates analog input values in engineering unit for each channel (1 – 16; 1 – 8 for J3). The unit is speci c to each input type: °C

for temperature, Volts for voltage, and % for potentiometer. The data are 32-bit oating values, which requires two consecutive

registers for one module.

(3) CHANNEL STATUS (30081 to 30096)

Indicates the current status of analog inputs (1 – 16; 1 – 8 for J3). The following list shows the names and descriptions of each bit.

BIT

NAME

DESCRIPTION

6

Input Overrange

Indicates the designated analog input is in overrange, de ned as one or

more of the following condition:

• ADC input value 0x0000 or 0xFFFF

• Burnout status for thermocouple, RTD and Potentiometer input

• Out of range de ned in the temperature table (thermocouple and RTD)

• ADC error

0 : Normal

1 : Overrange

7

ADC Error

Indicates the status of ADC.

0 : Normal

1 : Error

12

Cold Junction Compensation SW

Indicates whether the cold junction compensation is enabled or disabled,

for thermocouple input.

0 : Disable

1 : Enable

Others

Reserved

For system’s use
