Printed-circuit board connector - BCH-500V- 6 GN - 5445708

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Header, Nominal current: 12 A, Rated voltage (III/2): 320 V, Number of positions: 6, Pitch: 5 mm, Color: pastel

green, Contact surface: Tin, Assembly: Soldering

The figure shows a 5-pos. version of

the product in gray



Key commercial data

Packing unit

1 pc

Minimum order quantity

100 pc

Weight per Piece (excluding packing)

2.2 GRM

Custom tariff number

85366990

Country of origin

China

Technical data

Dimensions

Length

8.6 mm

Pitch

5 mm

Dimension a

25 mm

Pin dimensions

1 x 1 mm

Hole diameter

1.4 mm

General

Range of articles

BCH-V

Insulating material group

I

Rated surge voltage (III/3)

4 kV

Rated surge voltage (III/2)

4 kV

Rated surge voltage (II/2)

4 kV

Rated voltage (III/3)

250 V

Rated voltage (III/2)

320 V
