4 / 6 page

MODEL: LTCEC

LTCEC SPECIFICATIONS

ES-3373 Rev.9 Page 4/6

http://www.m-system.co.jp/

CONNECTION DIAGRAM

–

OUTPUT

LOAD

SOURCE

CONNECTOR*

CLAMP-ON SENSOR

U(+)

V(–)

*Connector provided only for the CLSA-08 and CLSA-12.

AUXILIARY POWER

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

54 (2.13)

72 (2.83)

[4 (.16)]

143 (5.63)

(.12)

DIN RAIL

35mm wide

8 (.31)

2–M4 MTG HOLE

16–M4 SCREW

TERMINAL COVER (option /T)

10 (.39)

• When mounting, no extra space is needed between units.

■ Sensor model No.: CLSA-08

10 (.39)

dia.

41 (1.61)

27 (1.05)

26 (1.02)

150 (5.91)

3000 (118)

■ Sensor model No.: CLSA-12

16 (.63)

dia.

44.5 (1.75)

30 (1.18)

31 (1.22)

150 (5.91)

3000 (118)

■ Sensor model No.: CLSA-30

24 (.94)

dia.

64 (2.52)

40 (1.57)

34 (1.34)

200 (7.87)

(.16)

■ Sensor model No.: CLSA-50

36 (1.41)

dia.

80 (3.15)

50 (1.97)

38 (1.50)

(.16)

200 (7.87)
