6 / 35 page

ADRF6780

Data Sheet

Rev. D | Page 6 of 35

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage

VPDT, VPRF

6.5 V

VPBB, VPLO, VPBI

4.3 V

VP18

2.3 V

Maximum Junction Temperature

125°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−55°C to +125°C

Lead Temperature Range (Soldering 60 sec)

−65°C to +150°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is thermal resistance, junction to ambient (°C/W), and θJC is

thermal resistance, junction to case (°C/W).

Table 3. Thermal Resistance

Package Type

θJA1

θJC1

Unit

32-Lead LFCSP

9.18

1.14

°C/W

See JEDEC Standard JESD51-2 for additional information on optimizing the

thermal impedance (printed circuit board (PCB) with 3 × 3 vias).

ESD CAUTION
