5.1
Bypass mode
In Bypass mode (FIFO_CTRL (13h)(TRIG_MODES and F_MODE[1:0] = ‘000’ or ‘100’), the FIFO is not
operational and it remains empty.
Switching to Bypass mode is also used to reset the FIFO. Passing through Bypass mode is mandatory when
switching between different FIFO buffer operating modes.
As described in the next figure, for each channel only the first address is used. When new data is available, the
older data is overwritten.
Figure 9. Bypass mode
P1
T1
P2
T2
Pi,T
empty
P0
T0
P127
T127
i
LPS27HHTW
Bypass mode
DS13489 - Rev 1
page 13/55
