MODEL: M3SMS

M3SMS SPECIFICATIONS

ES-7715 Rev.6 Page 3/3

http://www.m-system.co.jp/

EXTERNAL VIEW

1

2

3

4

Zero Adj.

Power LED

Span Adj.

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

7

8

5

6

1

2

3

4

12

(.47)

110.5 (4.35)

[5 (.20)]

• When mounting, no extra space is needed between units.

DIN RAIL

35mm wide

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

Isolation

S

Z

Output

Driver

OUTPUT

5

6

U(+)

V(–)

POWER

7

8

+

–

Low Drift

Amplifier

2

1

4

3

2

1

POTENTIOMETER

max.

min.

3

Excitation Volt.

Generator

POWER LED

Specifications are subject to change without notice.
