www.sensirion.com

Version 1.0 – July 2020 – D1

6/19

Condition

Parameter

Min.

Max.

Unit

Operating conditions

Relative humidity

0

90

% RH

Temperature

−10

50

°C

Operating conditions of

humidity compensation

Humidity

1.5 (−13)

–

30 (+31)

90

(the smaller)

or

% RH

Temperature

−10

50

°C

Storage conditions

Relative humidity

0

80

% RH

Temperature

5

30

°C

Table 4 Recommended humidity and temperature conditions for storing and operating the SGP40. Dew point refers to maximum humidity

allowed at minimum and maximum temperature, respectively.

Figure 3 Recommended relative humidity and temperature for

operating the SGP40. Green area marks conditions for which

humidity compensation has been optimized. Additionally, gray areas

mark operating conditions without using the humidity compensation

feature.

Figure 4 Recommended relative humidity and temperature for

storing the SGP40.

To ensure an optimal performance of the SGP40, Handling and Assembly Instructions for SGPxx Gas Sensors as well as the

Design-in Guide for Integrating SGP4x Gas Sensors need to be followed.

2.4 Absolute Minimum and Maximum Ratings

Stress levels beyond those listed in Table 5 may cause permanent damage to the device. Exposure to minimum/maximum

rating conditions for extended periods may affect sensor performance and reliability of the device.
