Data Sheet

ADAR2004

Rev. 0 | Page 11 of 37

RF INPUT FREQUENCY (GHz)

2.75V

2.50V

2.25V

Figure 13. Gain vs. RF Input Frequency and Supply Voltage (VCC) (Gain = 0x7)

IF OUTPUT FREQUENCY (MHz)

GAIN = 0x0

GAIN = 0x1

GAIN = 0x2

GAIN = 0x3

GAIN = 0x4

GAIN = 0x5

GAIN = 0x6

GAIN = 0x7

Figure 14. Gain vs. IF Output Frequency and Gain Setting (RF Input = 25 GHz)

IF OUTPUT FREQUENCY (MHz)

2.75V

2.50V

2.25V

Figure 15. Gain vs. IF Output Frequency and VCC (RF Input = 25 GHz,

Gain = 0x7)

RF INPUT FREQUENCY (GHz)

–10dBm

–15dBm

–20dBm

–25dBm

Figure 16. Gain vs. RF Input Frequency and LO Input Power

IF OUTPUT FREQUENCY (MHz)

+85°C

+25°C

–40°C

Figure 17. Gain vs. IF Output Frequency and Temperature (RF Input = 25 GHz,

Gain = 0x7)

–30

–25

–15

–5

–20

–10

RF INPUT FREQUENCY (GHz)

GAIN = 0x0

GAIN = 0x1

GAIN = 0x2

GAIN = 0x3

GAIN = 0x4

GAIN = 0x5

GAIN = 0x6

GAIN = 0x7

Figure 18. Input IP3 vs. RF Input Frequency and Gain Setting
